£622.00 Price incl. VAT: £746.40
Supplied with:
Supplied with:
| Features | Popular with |
|---|---|
| Easily locate & trace utilities | Excavation contractors |
| Work safely with usage alerts & system diagnostics | Utility installation & repair contractors |
| No technical experience necessary | General contractors |
| Depth range: up to 7m | Builders |
| Dust and water protection to IP66 | Gas & electricity companies |
| Highly visible digital LCD display | Cable TV companies |
| Robust light weight design | Pipe laying contractors |
View and download this product’s brochure, datasheet, and manual in a PDF format
| Brand |
Leica Geosystems |
|---|
|
MODE |
DA220 |
DA230 |
|---|---|---|
|
Induction Mode Frequencies |
33 / 8 kHz | 33 / 8 kHz |
|
Power Output |
Up to 1 Watt max |
Up to 1 Watt max |
|
Direct Connection Mode Frequencies |
131 kHz / 33 kHz / 8 kHz | 131 kHz / 33 kHz / 8 kHz / 512 Hz / 640 Hz |
|
Power Output* 1 Watt Model 3 Watt Model |
Up to 1 Watt max. |
Up to 1 Watt max. |
|
Environmental Standard |
IP67 | IP67 |
|
Operating Temperature |
20 °C to +50 °C |
20 °C to +50 °C |
|
Storage temperature |
-40°C to +70°C | -40°C to +70°C |
|
Battery |
7.4V Rechargable Li–ion |
7.4V Rechargable Li–ion |
|
Battery operating time ** |
15 h | 15 h |
|
Dimensions (HxWxD) |
250 x 206 x 113 mm |
250 x 206 x 113 mm |
|
Environmental Standard |
IP66 | IP66 |
|
Operating Temperature |
-20 °C to +50 °C |
-20 °C to +50 °C |
|
Battery |
7.4V Rechargeable Li – Ion | 7.4V Rechargeable Li – Ion |
|
Battery operating time *** |
15 h |
15 h |
|
Dimensions (HxWxD) |
765×290 x93mm 30.12 x11.42×3.66 inches |
765×290 x93mm 30.12 x11.42×3.66 inches |
|
Weight with batteries |
2.38Kg |
2.38Kg |
*Utility impedance of 300 Ohms
** Defined at 20°C (77°F) power level 2
Summary of Manufacturers Warranty
LEICA Geosystems AG (LEICA Geosystems), warrants to the original end user (Customer) that this Product will be free from defects in workmanship and materials, under normal use two (2) years shall apply, and (ii) batteries for which ninety (90) days shall apply, unless such warranty period has been extended by LEICA Geosystems, and provided any and all operating and maintenance instructions are strictly respected, in particular in case of extreme and/or continuous applications/use of the Product.
The warranty period begins on the proved purchase date (or if applicable, date of delivery or date of acceptance report). LEICA Geosystems sole obligation under this express warranty shall be, at LEICA Geosystems sole option and expense, to replace or repair the Product or part, or refund the purchase price paid for the Product. LEICA Geosystems warrants any repaired or replaced Product or part for a period of ninety (90) days from shipment, or through the end of the original warranty, whichever is longer. All Products or parts that are replaced become the property of LEICA Geosystems. This express warranty does neither cover consumables, such as reflectors, bulbs and fuses, nor third party products.
For full details contact Leica Geosystems, or go to www.disto.com
Leica Geosystems also excludes any liability, whether based in contract or tort (including negligence), for incidental, consequential, indirect, special, or punitive damages of any kind, or costs of procurement of substitute products by customer, or for the loss of revenue or profits, loss of business, loss of information or data, or other information or financial loss arising out of or in consequence with the sale, installation, maintenance, use, performance, failure, or interruption of this product, even if Leica Geosystems or its distributors have been advised of the possibility of such damages, and limits its liability to replacement, repair, or refund of the purchase price paid, at Leica Geosystems option. This limitation of liability for damages will not be affected if any remedy provided herein shall fail of its essential purpose.
To claim your 3 year warranty you can register your DISTO on the Leica Geosystems website.
