£235.00 Price incl. VAT: £282.00
Supplied with:
Forget about plumb bobs, string lines and spirit levels! The Leica Lino P5 point laser is practical and simple to operate. Just one button is needed for all its applications. It quickly and accurately projects all the points you need which makes it an efficient solution for professional plumbing and alignment tasks.
Supplied with:
The laser beam is projected above and below the instrument, allowing you to transfer reference dots quickly and efficiently.
The Lino P5 projects 3 laser dots at exactly the same height. Aligning windows, partition walls and other elements becomes quick and easy.
Magnetic smart adapters allow you to quickly attach your Leica Lino P5 to edges, profiles, iron pipes, tracks or bars, allowing you to complete your job faster.
With 5 laser beams at exact right angles. This simplifies setting out tasks and makes interior fitting-out more precise and efficient.
You can manually switch off the self-levelling using the lock function. The laser line can then be projected at any angle.
The Lino P5 automatically adjusts its positioning if it is slightly out of level to ensure the correct transfer of angles and reference points up to ± 4°. Flashing laser points mean that the tilt is outside this limit.
| Features | Popular with |
|---|---|
| Range up to 30m | Electricians, HVAC |
| Levelling accuracy ± 0.2mm @ 1m | Carpenters |
| Self-levelling range ± 4 ° | Plasterers |
| Number of laser points 5 | Decorators, painters |
| Beam direction – vertical, horizontal | |
| Protection class IP 54 | |
| Battery type: Alkaline | |
| Battery life: < 37 h |
View and download this product’s brochure, datasheet, and manual in a PDF format
| Brand |
Leica Geosystems |
|---|
| Range | up to 30 m depending on lighting conditions |
| Levelling accuracy | ± 0.2 mm / m |
| Self-levelling range | ± 4 ° |
| Self-levelling time | < 3 s |
| Number of laser points | 5 laser points – up, down, forward, right, left at exact 90° angles |
| Beam direction/fan angle | vertical / >180°, horizontal / >180° |
| Laser line width at 5m | < 2 mm |
| Laser type | 635 nm / class 2 (red) |
| Battery type | 3 x AA 1.5 V) |
| Operating time | 37h |
| Protection class | IP 54 |
| Dimensions |
110 × 60 × 100 mm |
| Weight with batteries |
495 g |
| Tripod thread Lino | 1/4″ |
Summary of Leica DISTO Manufacturers Warranty
LEICA Geosystems AG (LEICA Geosystems), warrants to the original end user (Customer) that this DISTO Product will be free from defects in workmanship and materials, under normal use three (3) years shall apply, and (ii) batteries for which ninety (90) days shall apply, unless such warranty period has been extended by LEICA Geosystems, and provided any and all operating and maintenance instructions are strictly respected, in particular in case of extreme and/or continuous applications/use of the Product.
The warranty period begins on the proved purchase date (or if applicable, date of delivery or date of acceptance report). LEICA Geosystems sole obligation under this express warranty shall be, at LEICA Geosystems sole option and expense, to replace or repair the Product or part, or refund the purchase price paid for the Product. LEICA Geosystems warrants any repaired or replaced Product or part for a period of ninety (90) days from shipment, or through the end of the original warranty, whichever is longer. All Products or parts that are replaced become the property of LEICA Geosystems. This express warranty does neither cover consumables, such as reflectors, bulbs and fuses, nor third party products.
For full details contact Leica Geosystems, or go to www.disto.com/warranty
Leica Geosystems also excludes any liability, whether based in contract or tort (including negligence), for incidental, consequential, indirect, special, or punitive damages of any kind, or costs of procurement of substitute products by customer, or for the loss of revenue or profits, loss of business, loss of information or data, or other information or financial loss arising out of or in consequence with the sale, installation, maintenance, use, performance, failure, or interruption of this product, even if Leica Geosystems or its distributors have been advised of the possibility of such damages, and limits its liability to replacement, repair, or refund of the purchase price paid, at Leica Geosystems option. This limitation of liability for damages will not be affected if any remedy provided herein shall fail of its essential purpose.
To claim your 3 year warranty you can register your DISTO on the Leica Geosystems website. The warranty extension is valid only if the device has been registered with www.disto.com/warranty within 8 weeks of purchase
As a main Leica Geosystems agent and warranty centre in the UK we can offer training, specialist product and advice and demonstration and trial of moisture measuring and surveying.
We also offer comprehensive telephone support and training including advice on which product would deliver the best value to you organisation and organizations business requirements. We have a number of sales agents that are on the road visiting customers up and down the UK and these are available for onsite trial and demonstrations.
This self-levelling, five-point red laser level, equipped for multiple applications.
