High-resolution thermal imaging camera for use in the construction industry, mechanical engineering and electrical engineering – perfect for detailed image analysis
This thermal imaging camera has a high-resolution infrared sensor and allows highly detailed image analysis as well as optimum visualisation of extremely small temperature differentials. It is an extremely versatile product due to the large measuring range: typical applications include the construction industry, mechanical engineering and electrical engineering.
One-click configuration allows the thermal imaging camera to be configured quickly in the CustomApp function via extensive parameter setups for a wide range of standard applications. The high thermal sensitivity also enables detection of thermal bridges and insulation errors in buildings, analysis of heating systems, location of overheated components, cables and fuses, and identification of defective solar cells in PV modules. The large, easy-to-read 3.5” display has a touchscreen facility for direct control. Manual focusing ensures perfect image quality at any distance. Analysis can be carried out on infrared, digital or MIX images.
The MIX image provides an extremely easy to interpret and comprehensive representation of the temperature profiles by combining digital and infrared images. Measured data can be saved to an exchangeable SD card and transferred to a PC via the USB-C interface.
Supplied with:
Introducing the ThermoCamera HighSense
High-resolution
3.5″ colour display for reliable evaluation & analysis of temperature conditions
Evaluation & Analysis
Analysis analysis of heating systems, location of overheated components, cables and fuses, and identification of defective solar cells in PV modules.
Extremely versatile
Typical applications include the construction industry, mechanical engineering and electrical engineering.
High thermal sensitivity
Enables detection of thermal bridges and insulation errors in buildings, analysis of heating systems.
Key Features
- High-resolution infrared sensor & allows highly detailed image analysis
- Optimum visualisation of extremely small temperature differentials.
- Extremely versatile with large measuring range
- High thermal sensitivity also enables detection of thermal bridges and insulation errors in buildings, analysis of heating systems, location of overheated components, cables and fuses, and identification of defective solar cells in PV modules
| MEASURED VARIABLE: | Infrared temperature |
| FEATURES: | Point Line Area min./max. Temperature range automatic |
| SCREEN TYPE: | 3,5″ TFT-Display |
| SENSOR TYPE: | uncooled microbolometer |
| DISPLAY RESOLUTION: | 640 x 480 pixels |
| SPECTRAL RANGE: | 8-14 μm |
| THERMAL SENSITIVITY (NETD): | 50 mK @30°C |
| MEASURING RANGE INFRARED TEMPERATURE: | -20°C … 150°C, 0°C … 650°C |
| ACCURACY INFRARED TEMPERATURE: | ± 2°C or 2% of measured value |
| INFRARED TEMPERATURE RESOLUTION: | 160 x 120 pixels |
| POWER SOURCE: | Li-ion battery pack 3.7V / 2.6Ah |
| OPERATING TIME: | approx. 4 hours |
| BATTERY RECHARGING TIME: | approx. 4 hours |
| OTHER FEATURES: | Choice of 9 languages |
| OPERATING CONDITIONS: | -15°C … 50°C, max. humidity 85% rH, no condensation, max. working altitude 2000 m above sea level |
| STORAGE CONDITIONS: | -20°C … 70°C, humidity 10 … 99% rH |
| DIMENSIONS (W X H X D): | 95 mm x 230 mm x 112 mm x (incl. batteries) |
| WEIGHT: | 530 g (incl. battery pack) |
